BM-16S Programmable Macropad (Choc Switches)
01 / 21
BM-16S Programmable Macropad (Choc Switches)
bookmark_border
Where's the price?
To negotiate the best possible price for our customers, we agree to hide prices prior to logging in.
1.2K requests
·
254 Sold
Product Description
If you have room for it, a mini pad makes an excellent companion to your keyboard. This kit comes with everything you need to build your own, including 16 low-profile Kailh Choc switches Read More
You Might Also Like
search
close
Sort by: Top Conversations
keyboard_arrow_downOrangutang
35
Apr 18, 2019
Got mine to work, staring shamelessly in awe at the RGB now! First QMK and I want to post and help other noobs like myself if possible.
My success stems completely from "textonly" and "blacksunix"posts under the BM-16A drop discussions https://www.massdrop.com/buy/bm-16a-16-key-programmable-mini-pad-kit/talk/2331792
READ these. The only changes I made were to use the json layout files for the BM-16S from the Google Drive
Get: QMK Toolbox from Github, install it
Get: the default JSON and instructions from manufacturer Google Drive. This is on their Aliexpress page for the BM-16A as mentioned by "jf647" here. So you can just search for it as well.
- I used https://kbfirmware.com/ to modify my layout. Upload the "BM16S.json" file from the manufacturer Google Drive pack into kbfirmware.com
- This loads the basic layout in kbfirmware.com. Customize it
- Backup your json if you wish under the Settings tab. Then go to the Compile tab and export the ".Hex" file and load it into QMK Toolbox. Make sure the right chip is correctly selected in the toolbox UI
- Connect the board to the computer. I shorted the reset pins, labeled "RE" next to the smaller of the board chips, with a pair of needle nose pliers. Definitely gonna solder and run an external switch there at some point...
- The keypad will be put into DFU mode with this reset, and will then be visible in the QMK Toolbox console. Here you can flash your custom Hex file to the board
- Unplug, replug
(Edited)
Orangutang
35
Aug 2, 2019
Huh I have no idea, I have "RGB_MODE_FORWARD" as one key to cycle the modes, but I'm not sure how to program individual ones if it's even possible. Would be interested if it was
cdog911
7
Jan 17, 2019
This would be perfect if it was wireless (still tempting)
Not sure why nobody seems to make a wireless macro pad yet. I've been using a wireless mechanical number pad instead.
cdog911
7
May 14, 2019
True. I'd have been ok with a non LED solution.
I ended up picking up an Elgato Stream Deck for my macros.
jwordfish
67
May 14, 2019
cdog911Dang that's a hella good price for LCD keys, assuming this site showing it for $80 is legit
(Edited)
.png?auto=format&fm=jpg&fit=crop&w=30&h=30&dpr=1&q=70)
SuchFNS
1
Jan 21, 2019
Check out dygma.com they are basically head on with what you are asking for. Essentially two separate "pads" that can connect together to form a keyboard, multiple thumb keys where the space bar would go, with the main downside being that its quite a bit pricey, but definitely something unique.
canyoudig
90
May 14, 2019
With these hotswappable switches, can you plug in regular MX stem switches? I know it'll make the profile much higher, but just asking.
erickong
7412
Mech Keys Moderator
May 14, 2019
canyoudigNo. The metal contacts are in a different position
MagicSmoke
388
Jan 30, 2020
obermanMake a patch out of aluminum foil and tape it to your upper arm. Either. Wear it for eight weeks.
mjoseph97
82
May 14, 2019
How do you program the keys, and where can i find my information about the product? "BM Workshop" and "BM Workshop keyboards" google searches just bring up BMW repair shops.
MountainPass
223
May 14, 2019
mjoseph97Under "Specs", it says "Fully programmable with macros (QMK supported)". So you can use QMK software to program it.
Capsy
4
Jan 17, 2019
Anyone has any guide on the kailh choc switches? I'd like to know the specs of each color for the switches mentioned here.
VadimGut
5
Jan 18, 2019
you should really adopt stackoverflow mentality and attach a link to the resource :)
UD98
11
Jan 20, 2019
VadimGutYou can find the spec sheets here. It's the standard linear/tactile/clicky with 50 and 70g actuation force
https://novelkeys.xyz/products/kailh-low-profile-switches
https://novelkeys.xyz/products/novelkeys-x-kailh-low-profile-heavys
https://novelkeys.xyz/products/novelkeys-x-kailh-low-profile-heavys
ipsum
0
Jul 17, 2019
I'm able to use this device by plug and play means, but I'm having an issue when trying to put this device in DFU mode. I've tried using the RESET macro and shorting the board, both produce the same result. Windows 10 recognizes that something changed and I end up with an unknown "ATm32U4DFU" device in Device Manager. If I unplug and plug, the device returns to normal. However, QMK Toolbox never detects the device throughout all of this. Any help would be greatly appreciated.
equuleus
20
Aug 4, 2019
Sorry for my late reply.
I'm also looking for a tool for setting the lighting of each key individually, but not find yet.
By the way, I found the manual for BM-16s.
Access here, download the files and extract them (source).
HellJumper406
4
May 14, 2019
I think it looks really nice, Waiting till August to get it not so nice....
A community member
May 15, 2019
HellJumper406This is pretty standard for mechanical keyboard drops in general
fvae
8
May 14, 2019
Do I need to solder or do anything other than snap together stuff? Does programming allow for multikey macros with time delays? Whats the onboard memory/max keystroke limit for each key?
erickong
7412
Mech Keys Moderator
May 14, 2019
fvaeIt is hot swappable so no solder is necessary. Just snap everything together and tighten some screws
