Gustard X16 MQA DAC

Gustard X16 MQA DAC

bookmark_border
Where's the price?
To negotiate the best possible price for our customers, we agree to hide prices prior to logging in.
314 requests
Product Description
Continuing to lead the pack in DAC performance, Gustard is back with the X16: a feature-loaded conversion powerhouse with the latest DAC chipset. In this case, it’s two ESS ES9068S DAC chips—both of which are capable of MQA decoding, giving listeners access to raw, uncompressed sounds straight from the studio Read More

MQA Decoding, Class-Leading Transparency

Continuing to lead the pack in DAC performance, Gustard is back with the X16: a feature-loaded conversion powerhouse with the latest DAC chipset. In this case, it’s two ESS ES9068S DAC chips—both of which are capable of MQA decoding, giving listeners access to raw, uncompressed sounds straight from the studio. With other high-end components like an XMOS XU216 processor and dual American-made ACCUSILICON femtosecond crystal oscillators, the X16 achieves less than 0.0001-percent THD and crosstalk levels less than 130 decibels. A wide range of inputs and outputs makes this high-performance DAC easy to integrate into any setup, while two-way Bluetooth with support for LDAC, aptX Low Latency, and aptX HD codecs ensures the highest level of wireless connectivity.

Gustard X16 MQA DAC
Gustard X16 MQA DAC
Gustard X16 MQA DAC
Gustard X16 MQA DAC

Model

Specs

General

  • Gustard
  • DAC chipset: (2) ES9068S DACs
  • Processor: XMOS xCORE-200 series 16-core XU216
  • Digital processing chip: ALTERA CPLD logic array chip
  • (2) ACCUSILICON femtosecond crystal oscillators
  • Op-amp: OPA1612A
  • MQA full expansion decoding support
  • Optical, coaxial, IIS, and AES inputs support MQA hardware rendering
  • Inputs: Optical, IIS-H, AES, coaxial, USB, Bluetooth
  • Outputs: Stereo XLR, stereo RCA, Bluetooth
  • Bluetooth version: Bluetooth 5.0
  • Bluetooth codecs supported: LDAC, AAC, SBC, aptX, aptX LL, aptX HD
  • White light OLED display
  • Remote control functionality
  • Amplitude frequency response: 20 Hz – 20 kHz (± 0.08 dB)
  • DNR: >126 dB
  • Crosstalk: -130 dB (1 kHz)
  • THD + N: <0.0001% (1 kHz)
  • IMD: <0.0004% (-1 dBFs)
  • RCA output level: 1 Vrms (0 dB volume, 100-ohm impedance)
  • XLR output level: 4 Vrms (0 dB volume, 300-ohm impedance)
  • AC power supply: AC 115V / 230V 50/60 Hz
  • Power consumption: <15W
  • Dimensions: 8.6 x 1.9 x 6.6 in (22 x 5 x 17 cm)
  • Weight (packaging): 5.5 lbs (2.5 kg)

Sampling Rates

  • Coaxial: 16-bit – 24-bit / 44.1–192 kHz PCM; DSD DOP64
  • AES: 16-bit – 24-bit / 44.1 – 192 kHz PCM; DSD DOP64
  • Optical: 16-bit – 24-bit / 44.1 – 192kHz PCM; DSD DOP64
  • USB: 16-bit – 24-bit / 44.1 – 768 kHz PCM; DSD DOP64-DOP256; Native DSD: DSD64-DSD512
  • IIS-H: PCM 16-bit – 24-bit / 44.1 – 768 kHz PCM; DSD DOP64-DOP256; Native DSD: DSD64-DSD512
  • Bluetooth 5.0: LDAC can achieve 24-bit / 96 kHz high-code transmission

Shipping

Estimated ship date is July 24, 2023 PT.

Payment will be collected at checkout. After this product run ends, orders will be submitted to the vendor up front, making all orders final.

Shop Our Curated Deskscapes
Explore these specially curated spaces to find inspiration for yours.
View All
Top Customer Questions12
search
close
Question
USB is not mentioned as MQA capable in the specs, or my eyesight is failing me. Can you please clarify? Thanks.
Mar 20, 2021
Top Answer
BrianF
25
Yes, the USB is MQA capable. I'm using the X16 with Tidal MQA over USB and it works great.Read More
Mar 20, 2021
Question
Would using a MacBook Pro, the Tidal App, and a USB connection with this DAC allow for the highest resolution possible?
Mar 21, 2021
Top Answer
BrianF
25
Yes, especially with their MQA and various 96kHz or 192kHz tracks. I have Tidal settings set to exclusive mode and passthrough MQA as well.Read More
Mar 21, 2021
Question
Does this DAC have volume control for use with active speakers?
Mar 22, 2021
Top Answer
bhazard451
120
Yes, it has digital volume control.Read More
Mar 24, 2021
