HICAT Livera Arduino-Compatible Camera Robot Kit

HICAT Livera Arduino-Compatible Camera Robot Kit

bookmark_border
Where's the price?
To negotiate the best possible price for our customers, we agree to hide prices prior to logging in.
37 requests
Product Description
Ever wanted to build your own robot? Now you can Read More

Build Your Own Arduino-Controlled Robot

Ever wanted to build your own robot? Now you can. The HICAT Livera camera robot kit comes with all you need to assemble a programmable robot at home. Inside, you’ll find a HICAT Livera board, motor driver board, camera module, Livera camera cable, two-gigabyte SD card with built-in firmware, E-MAX SERVO, DC gear motors, and the hardware to build a functioning robot. The HICAT Livera board can be paired through Wi-Fi and contains everything necessary to support the microcontroller. Just connect it to a computer via USB or power it with the 3.3-volt Lipo battery. The microcontroller supports thousands of open source codes and can be programmed to create new functions. Finally, the camera module can capture video and photos, has open CV-compatible image processing, and can store files on the onboard SD card.

Note: This drop has limited quantities available.

HICAT Livera Arduino-Compatible Camera Robot Kit
HICAT Livera Arduino-Compatible Camera Robot Kit
HICAT Livera Arduino-Compatible Camera Robot Kit
HICAT Livera Arduino-Compatible Camera Robot Kit
HICAT Livera Arduino-Compatible Camera Robot Kit
HICAT Livera Arduino-Compatible Camera Robot Kit
HICAT Livera Arduino-Compatible Camera Robot Kit
HICAT Livera Arduino-Compatible Camera Robot Kit

Specs

  • HICAT
  • Arduino compatible
  • 720p HD video and photo capturing
  • Open CV-compatible image processing
  • Image capturing and data recording onto the onboard SD card
  • Mobile observation and manipulation (web-based and native)
  • Visual enabled line follower
  • Color sensing
  • Wi-Fi enabled

Livera Board

  • Vision core: hi3518
  • Storage: 16 megabyte flash + SD card
  • MCU: ATmega32U4
  • Wifi: MT7601
  • MPU6050 accelerometer and gyroscope
  • Power supply: 3.3V LiPo battery, 5V USB 200 mAh

Camera

  • Sensor: OV9712
  • View angle: 140°

Extend Cable

  • Size: 4.7 in (12 cm)
  • Type: FPC

Motor Driver

  • Core: LV8548 H-bridge
  • Power: 5V microUSB port, 5–12V input
  • Output: 4 channel DC, 4 channel servo
  • 5V power switch

Technical Details

  • Finished dimensions: 7.6 x 4.8 x 3.1 in (19.3 x 12.3 x 8 cm)
  • Weight: 12.6 oz (360 g)

Included

  • HICA Livera board
  • Livera motor driver board
  • Livera camera extend cable
  • Livera camera module
  • 2G SD card
  • Livera guide book
  • Livera robot assembly guide book
  • (2) 9V LiPo battery with bat carrier
  • E-MAX SERVO
  • DC gear motor, motor carrier
  • Robot base acrylic panels
  • Omnidirectional wheel set
  • (4) M2x15(+6)mm nylon studs
  • (4) M2x6mm nylon studs
  • (8) M2x6(+6)mm nylon studs
  • (8) M2x10(+6)mm nylon studs
  • (4) M2 nylon nuts
  • 5V laser beam
  • Stickers
  • USB cable
  • Screwdriver
