Kailh and NovelKeys created their Box MX Mechanical Switches as a way to provide extra-sturdy key switches with substantial feel and sound. The Box Jade is a true testament to that spirit, featuring an operating force of 50 grams required, tactile force of 55 grams, and a bottom-out requirement of 60 grams for a really nice amount of pressure for tactile operation. The Box Jade switches are also known for gem-like brilliance with a satisfying, well-rounded sonic feedback while you’re typing. Kailh and NovelKeys have also made sure these switches are durable by building in IP56 water and dust resistance and rating each switch up to 70 million actuations. The translucent top and white bottom provide a clean look for the jade green stem to pop out of, and thanks to 3-pin hot-swappable compatibility, these switches are ready to give you board a gem-like style without soldering.
Kailh x NovelKeys
35 unit pack
Operation type: Clicky
Translucent top housing
White bottom housing
IP56 waterproof and dustproof
Operating force: 50 gf (± 10 gf)
Bottom-out force: 60 gf (± 10 gf)
Tactile force: 55 gf (± 10 gf)
Pretravel: 1.8 mm (± 0.3 mm)
Pressure point: 1.7 mm
Total travel: 3.6 mm (± 0.3 mm)
Reset point: 1.8 mm
3-pin PCB mount
Cherry MX compatible
Lifespan: 70 million actuations
Estimated ship date is Feb 9, 2023 PT.
Payment will be collected at checkout. Cancellations are accepted up to 2 hours after checkout, after which all sales final.
