Onkyo RZ630/730/830 Dolby Atmos/DTS:X Receivers

Onkyo RZ630/730/830 Dolby Atmos/DTS:X Receivers

bookmark_border
Where's the price?
To negotiate the best possible price for our customers, we agree to hide prices prior to logging in.
499 requests
Product Description
A 9.2-channel receiver with all the latest features, the Onkyo TX-RZ630  delivers powerful, dynamic sound for movies and music alike. Featuring Dolby Atmos, the receiver reproduces object-oriented sound in smooth, curving movements for an immersive audio experience Read More

Full-Featured Receiver With Bluetooth, Wi-Fi & More

 A 9.2-channel receiver with all the latest features, the Onkyo TX-RZ630  delivers powerful, dynamic sound for movies and music alike. Featuring Dolby Atmos, the receiver reproduces object-oriented sound in smooth, curving movements for an immersive audio experience. With next-generation DTS Neural X technology, it finds spatial cues in legacy soundtracks and re-formats them for playback through the height channels. Integrated Chrome-cast allows you to use your smartphone or tablet to stream music, while Google Assistant lets you control everything using voice commands. The HDMI inputs and outputs allow for 4K UltraHD to pass through at 60 frames per second, while HDR and BT.2020 create a consistent color spectrum across all formats of video. Finally, built-in Wi-Fi, Bluetooth, and AirPlay give you a variety of different ways to connect and stream apps like Pandora, Spotify, and VTuner.  The TX-RZ730 and TX-RZ830 add THX Certified Select Theater Reference Sound, additional multi-channel pre-outs, processing for 7.2.4 (with amp) and more power.

Note: The drop price listed is the “Minimum Advertised Price” set by the manufacturer. Massdrop is not allowed to advertise lower than the MAP price. The following options are available at checkout.

TX-RZ630

TX-RZ730

TX-RZ830

 The products offered in this drop are brand-new US goods, never opened, and will have a full warranty with Onkyo.

TX-RZ630

Onkyo RZ630/730/830 Dolby Atmos/DTS:X Receivers
Onkyo RZ630/730/830 Dolby Atmos/DTS:X Receivers

TX-RZ730

Onkyo RZ630/730/830 Dolby Atmos/DTS:X Receivers
Onkyo RZ630/730/830 Dolby Atmos/DTS:X Receivers

TX-RZ830

Onkyo RZ630/730/830 Dolby Atmos/DTS:X Receivers
Onkyo RZ630/730/830 Dolby Atmos/DTS:X Receivers

Specs - TX-RZ630

 General

  • Channels: 9.2
  • Power Output per Channel: 90 W per channel (8 Ohms, 20 Hz to 20 kHz, 0.08% THD, 2 channels driven, FTC), 215 W per channel (6 Ohms, 1 kHz, 10% THD, 1 channel driven)
  • Dynamic Power per Channel: 120 W (8 Ohms, front), 210 W (4 Ohms, front), 240 W (3 Ohms, front)
  • THD and Noise: 0.08% (20 Hz to 20 kHz, half power)
  • Frequency Response: 5 Hz to 100 kHz / +1 dB, -3 dB (Direct Mode)
  • Tone Control: (Bass): ±10 dB, 20 Hz, (Treble): ±10 dB, 20 kHz
  • Signal-to-Noise Ratio: 106 dB (line, IHF-A), 80 dB (phono, IHF-A)
  • Speaker Impedance: 4 to 16 Ohms

Features

  • Dynamic Audio Amplification
  • H.C.P.S. (High Current Power Supply)
  • Non-Phase Shift Amplifier
  • Continuous 6 Ohms Rated
  • Certified 4 Ohms Performance
  • Discrete Output Stage Circuit
  • Bi-amp Capability For Front
  • Dolby Atmos
  • 32-Bit Digital Signal Processing Engine
  • Dolby Decoder: Atmos, True HD, DD Plus, Dolby Surround
  • DTS:X
  • DTS Decoder: DTS:X, DTS-HD Master Audio, DTS 96/24, Neural:X, DTS-ES, DTS Express
  • ONKYO Surround Modes: Rock, Sports, Action, RPG
  • VLSC for Noiseless Audio Processing: Front Channels
  • CinemaFILTER
  • AccuEQ Room Calibration: X Advance (w/ AccuReflex)
  • Advanced Music Optimizer
  • 384K/32 Bit DACs

Processing

  • Dolby: Dolby Atmos, Dolby TrueHD,
  • DTS: DTS:X, DTS-HD Master Audio

Video Section

  • Input Sensitivity/Output Level and Impedance: (Component Y) 1.0 Vp-p/75 Ohms, (Component B/R) 0.7 Vp-p/75 Ohms, (Composite) 1.0 Vp-p/75 Ohms

Tuner

  • Tuning Frequency Range: (FM) 87.5 to 107.9 MHz, (AM) 530 to 1710 kHz
  • FM/AM Preset Memory: 40 stations

Connectivity

  • Wi-Fi: Dual-band 2.4 / 5 GHz
  • Bluetooth: Version: 4.1 + LE
  • Profile: A2DP v1.2, AVRCP v1.3
  • AirPlay

Inputs

  • HDMI: 7
  • Component Video: 2
  • Composite Video: 2
  • Optical TOSLINK: 2
  • Digital Coaxial: 1
  • Stereo RCA: 6
  • Stereo RCA Phono: 1 with ground screw
  • Audio: ⅛ in (3.5 mm)
  • USB: 1

Outputs

  • HDMI: 2
  • Stereo RCA: 1 zone 2 line out
  • Subwoofer pre-out: 2
  • Headphone: ¼ in (6.35 mm)

Interfaces

  • Ethernet
  • Setup mic in
  • IR: ⅛ in (3.5 mm)
  • RS-232 in
  • 12V Trigger Out: ⅛ in (3.5 mm)
  • AM antenna
  • FM antenna
  • Speaker Connectors: 9 binding post pairs
  • Input Sensitivity and Impedance: 200 mV/47 kOhms (Line), 3.5 mV/47 kOhms (Phono)
  • RCA Output Level and Impedance: Zone Line Out, Rated: 200 mV/2.3 kOhms
  • Subwoofer Pre Out, Rated: 1 V/470 Ohms
  • Zone Pre-Out, Rated: 2.0 V/2.3 kOhms

Physical

  • Power Requirements: 120 VAC, 60 Hz
  • Power Consumption: (Typical) 740 W, (On, No Sound) 70 W, (Standby) 0.15 W
  • Dimensions: 17.1 x 6.9 x 14.9 in (43.5 x 17.7 x 37.9 cm)
  • Weight: 22.5 lbs (10.2 kg)

Specs - TX-RZ730

 General

  • Channels: 9.2
  • Power Watts/Ch (8 Ohms 1kHz, 2 Channels Driven, FTC) 100, 0.08% THD
  • Power Watts/Ch (6 Ohms 1kHz, 1 Channel Driven, FTC) 225, 10% THD
  • Output, All Channels: 100 W/Ch (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC), 225 W/Ch (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)
  • Dynamic Power: 250 W (3 Ohms, Front), 220 W (4 Ohms, Front), 130 W (8 Ohms, Front)
  • THD+N (Total Harmonic Distortion + Noise): 0.08% (20 Hz-20 kHz, half power)
  • Input Sensitivity and Impedance: 200 mV/82 k-ohms (Line), 3.5 mV/47 k-ohms (Phono MM)
  • Rated RCA Output Level and Impedance: 1 V/470 Ohms (Sub pre-out), 1 V/2.3 k-Ohms (Zone Pre Out), 1 V/200 mV/470 ohms (Zone pre/line out)
  • Frequency response: 5 Hz–100 kHz/+1 dB, -3 dB (Direct Mode)
  • Phono Overload: 70 mV (MM, 1 kHz, 0.5%)
  • Tone Control: ±10 dB, 20 Hz (Bass), ±10 dB, 20 kHz (Treble)
  • Signal-to-Noise Ratio: 106 dB (Line, IHF-A), 80 dB (Phono, IHF-A)
  • Speaker Impedance: 4–16 ohms

Features

  • Sonos authorized (works with Sonos)
  • Dynamic Audio Amplification
  • H.C.P.S. (High Current Power Supply)
  • Non-Phase Shift Amplifier
  • THX Certified
  • Continuous 6 Ohms Rated
  • Certified 4 Ohms Performance
  • Discrete Output Stage Circuitry
  • Independent Block Construction (Analog/Digital)
  • Bi-amp Capability For Front
  • Dolby Atmos
  • 32-Bit Digital Signal Processing Engine
  • Dolby Decoder, Atmos, True HD, DD Plus, Dolby Surround
  • DTS:X
  • DTS Decoder, DTS:X, DTS-HD Master Audio, DTS 96/24, Neural:X, DTS-ES, DTS Express
  • 7.2.4ch Speaker Setup Support
  • ONKYO GAME Surround Modes: Rock, Sports, Action, RPG
  • VLSC for Noiseless Audio Processing: Front Channels
  • THX Processing Mode
  • AccuEQ Room Calibration: X Advance (w/ AccuReflex)
  • Direct/Pure Mode: X/-
  • Advanced Music Optimizer
  • 384K/32 Bit DACs

Connectivity

  • Analog Audio in: 7 (Includes 1 Phono Input)
  • Phono Input
  • Digital Audio IN (OPT/COAX): 2 / 1
  • Composite Video I/OL 2 / 0
  • Component Video I/O: 2 / 0
  • Front Panel HDMI
  • Front-Panel A/VL: 3.5mm audio input
  • USB Input: Rear
  • HDMI I/O: 7 / 2 (Main/Zone 2/Sub)
  • HDMI 4K/60 Hz- Capable HDMI Terminals
  • HDCP 2.2 Copy-Protection Compatibility
  • HDMI Support for High Dynamic Range: HDR10, Dolby Vision, HLG Support
  • HDMI Support for 3D, Audio Return Channel and CEC
  • BT.2020 Support
  • HDMI Support for Deep Color, x.v.Color, LipSync
  • HDMI Support for DVD-Audio, SACD, Multichannel PCM
  • Analog To HDMI Upconversion
  • 4K Passthrough
  • Analog Pre-Outs: 11.2
  • Powered Zone 2
  • Powered Zone 3
  • Zone 2 Line Out: Analog RCA, variable volume
  • Zone 2 Video Out: HDMI
  • Zone 2 Digital to Analog Audio Conversion: Net, SPDIF, HDMI
  • Zone 3 Line Out: Analog RCA, variable volume
  • Works with Sonos: Requires FW update & Sonos Connect
  • Whole House Mode
  • FlareConnect Multi-room Audio
  • Airplay
  • Google Chromecast built-in: Works with Google Assistant
  • DTS Play-Fi via Onkyo Music Control app
  • Onkyo App Support Onkyo Controller and Music Control apps
  • Internet Radio Capable: TuneIn
  • Spotify Connect Support
  • Amazon Music
  • Tidal
  • Streaming Audio From PC / Network
  • Hi-Res Streaming Audio Formats
  • Streaming Audio From USB memory
  • Wireless Network: IEEE 802.11 a/b/g/n 5 Ghz / 2.4 Ghz
  • Bluetooth: Version 4.1 + LE (Compatible Profile: A2DP v1.2, AVRCP v1.3)

Integration

  • RS-232
  • IR Input
  • Ethernet
  • RIHD (Remote Interactive Over HDMI)
  • 12V Trigger

Video

  • Input Sensitivity/Output Level and Impedance -
  • Video Input Sensitivity: 1 Vp–p/75 Ohms (Component Y), 0.7 Vp–p/75 Ohms (Component PB/CB, PR/CR), 1 Vp–p/75 Ohms (Composite)

Tuner

  • Tuning Frequency Range: (FM) 87.5–1070.9 MHz, (AM) 530–1,710 kHz
  • FM/AM Preset Memory: 40 stations

Physical

  • Power Supply: AC 120 V~, 60 Hz
  • Power Consumption: 750 W
  • No-Sound Power Consumption: 70 W
  • Standby Power Consumption: 0.15 W
  • Dimensions: 17.125 x 6.9 x 14.9 in (43.5 x 17.7 x 37.9 cm)
  • Weight: 23.8 lbs (10.8 kg)

Specs - TX-RZ830

 General

  • Channels: 9.2
  • Power Watts/Ch (8 Ohms 1kHz, 2 Channels Driven, FTC) 120, 0.08% THD
  • Power Watts/Ch (6 Ohms 1kHz, 1 Channel Driven, FTC) 250, 10% THD
  • Dynamic Audio Amplification
  • H.C.P.S. (High Current Power Supply)
  • Non-Phase Shift Amplifier
  • THX Certified
  • Continuous 6 Ohms Rated
  • Certified 4 Ohms Performance
  • Discrete Output Stage Circuitry
  • Independent Block Construction (Analog/Digital) 
  • Bi-amp Capability For Front 

Processing

  • Dolby Atmos
  • 32-Bit Digital Signal Processing Engine
  • Dolby Decoder Atmos, True HD, DD Plus, Dolby Surround
  • DTS:X
  • DTS Decoder DTS:X, DTS-HD Master Audio, DTS 96/24, Neural:X, DTS-ES, DTS Express
  • 7.2.4ch Speaker Setup Support (requires external power amp)
  • ONKYO GAME Surround Modes: Rock, Sports, Action, RPG
  • VLSC for Noiseless Audio Processing: Front Channels
  • THX Processing Mode
  • AccuEQ Room Calibration: X Advance (w/ AccuReflex)
  • Direct/Pure Mode
  • Advanced Music Optimizer 
  • 384K/32 Bit DACs 

Connectivity

  • Analog Audio IN: 7 (Includes 1 Phono Input)
  • Phono Input
  • Digital Audio IN (OPT/COAX): 2 / 1
  • Composite Video I/O: 2 / 0
  • Component Video I/O: 2 / 0
  • Front Panel HDMI
  • Front-Panel A/V: 3.5mm audio input
  • USB Input: Rear
  • HDMI I/O: 8 / 2 (Main/Zone 2/Sub)
  • HDMI 4K/60Hz: Capable HDMI Terminals
  • HDCP 2.2 Copy-Protection Compatibility
  • HDMI Support for High Dynamic Range: HDR10, Dolby Vision, HLG Support
  • HDMI Support for 3D, Audio Return Channel and CEC
  • BT.2020 Support
  • HDMI Support for Deep Color, x.v.Color, Lip Sync
  • HDMI Support for DVD-Audio, SACD, Multichannel PCM
  • Analog To HDMI Upconversion
  • 4K Passthrough 
  • Analog Pre-Outs: 11.2
  • Powered Zone 2
  • Powered Zone 3
  • Zone 2 Line Out: Analog RCA, variable volume
  • Zone 2 Video Out: HDMI
  • Zone 2 Digital to Analog Audio Conversion: Net/SPDIF/HDMI
  • Zone 3 Line Out: Analog RCA, variable volume
  • Works with Sonos (requires FW update & Sonos Connect)
  • Whole House Mode
  • FlareConnect Multi-room Audio
  • Airplay
  • Google Chromecast built-in (works with Google Assistant)
  • DTS Play-Fi (via Onkyo Music Control app)
  • Onkyo App Support (Onkyo Controller and Music Control apps)
  • Internet Radio Capable (TuneIn)
  • Spotify Connect Support
  • Amazon Music (accessible via Onkyo Music Control app)
  • Tidal
  • Streaming Audio From PC/Network
  • Hi-Res Streaming Audio Formats
  • Streaming Audio From USB memory
  • Wireless Network: IEEE 802.11 a/b/g/n 5 Ghz / 2.4 Ghz
  • Bluetooth: Version 4.1 + LE (Compatible Profile: A2DP v1.2, AVRCP v1.3)

Integration Access

  • RS-232 
  • IR Input 
  • Ethernet 
  • RIHD (Remote Interactive Over HDMI)
  • 12V Trigger 

Physical

  • Power Requirements: 120 VAC, 60 Hz
  • Power Consumption: Typical: 870 W
  • On, No Sound: 70 W
  • Standby: 0.15 W
  • Dimensions: 17.1 x 7.9 x 15.7 in (43.5 x 20.1 x 39.8 cm)
  • Weight: 30.9 lbs (14 kg)

Included

 Onkyo’s 3-year warranty

Shipping

Estimated ship date is Oct 24, 2018 PT.
