Product Description
If you're looking for a high-end AV receiver to complete your home entertainment system, the Pioneer Elite VSX Series AV receivers have you covered. Featuring Dolby Atmos, each model reproduces object-oriented sound in smooth, curving movements for an immersive experience Read More
Clear Audio With the Latest Dolby Technologies
If you're looking for a high-end AV receiver to complete your home entertainment system, the Pioneer Elite VSX Series AV receivers have you covered. Featuring Dolby Atmos, each model reproduces object-oriented sound in smooth, curving movements for an immersive experience. With next-generation DTS: X technology, the receiver automatically adapts audio to existing channels with no specific speaker layout required, so you get rich, lifelike sound without the hassle. Additionally, it supports passthrough for HDCP 2.2, so you can enjoy 4K video without worrying about upgrading devices in the future. Built-in Wi-Fi and Bluetooth give you different ways to connect and stream apps like Pandora, Spotify, and VTuner. Integrated Chromecast allows you to use your smartphone or tablet to stream music. Finally, the MCACC Auto Room Tuning system lets you create the ideal acoustic environment, automatically compensating for differences in speaker size, level, and distance by equalizing the response for each.
Note: At checkout, choose the VSX-LX103 , the SC-LX303, or the VSX-LX503 . The drop price listed is the Minimum Advertised Price set by the manufacturer. Massdrop is not allowed to advertise a lower price than the MAP price. Final price will be shown at checkout.
SC-LX303
SC-LX503
Model Options
VSX-LX103 (-$170)
VSX-LX303 (-$50)
VSX-LX503 (+$200)
Specs
VSX-LX103
Power
- Amplifier design: Discrete Direct Energy
- Channels: 7.2
- Power output, watts per channel (20 Hz – 20 kHz, THD 0.08 % @ 8 ohms FTC): 80 watts
- Estimated power consumption/standby with HDMI control off: 460 W/0.15 W
- Power output, watts per channel (6 ohms 1 kHz 10 % 1ch Driven): 170 watts
- 4 OHM speaker
Handheld & Internet
- AirPlay
- Made for iPhone and iPod: AirPlay only
- iOS/Android remote control APP: Pioneer Control App
- Internet radio: TuneIn radio
- Pandora
- Streaming audio from PC/network
- Music playback via USB network: MP3, WMA, AAC, Apple Lossless, WAV, FLAC, AIFF, DSD
- Chromecast
- Hi-Res audio: Apple lossless, WAV, FLAC, and AIFF for 192kHz/24bit, DSD for 5.8MHz (via USB or wired network)
- TIDAL music streaming
Decoders & Formats
- Digital Core DSP Engine: Digital Quad-Core 32-bit DSP (Cirrus Logic)
- Audio DACs: 384 kHz/32-bit D/A Conversion with AK4458 (AKM)
- High-Definition Copy Protection (HDCP): 2.2
- Dolby Atmos
- Dolby TrueHD
- Dolby Digital Plus
- Dolby Surround
- DTS:X
- DTS Neo:X
- DTS Neural:X
- DTS-HD Master Audio
- HDMI SACD Transfer: Multi: 2.8MHz (PCM Conversion）
Soundfield Calibration
- MCACC
- MCACC Memory: 1
- Phase Control
- Symmetric EQ
- Auto Subwoofer Crossover
Listening Modes
- Auto Surround
- Stream Direct: Direct / Pure Direct
- Advanced Surround: Multiple
- Front Stage Surround Advance
Audio Features
- DSD Music File: 2ch:5.6MHz, Multi:2.8MHz(Multi is only for SACD via HDMI)
- Advanced Sound Retriever
- Tone Control: Multi
- Sound Delay (Lip Sync): 500 ms @ 48k/ 400 ms @ 96k/ 200 ms @ 192k
- Bi-Amp
Video Processing
- 4K 60p Ultra HD Passthrough: HDR10, Dolby Vision Compatible)
- 4K 60p Ultra HD Video Scaler: Ultra HD Upscaling
- 3D Ready
- Audio Return Channel
- HDMI 36-bit Deep Color
- x.v.Color
- Video Converter to HDMI
- Video Scaler: 1080p -> 4k
- Super Resolution
Connectivity
- HDMI Input / Output: 6 in / 1 out
- Wi-Fi Built-In: Dual Band 5 GHz/2.4 GHz
- Bluetooth Built-In: Version: 4.1, Profile: A2DP/AVRCP, Codec: SBC/AAC
- Component Video Input / Output: 1 In (Assignable)
- USB Memory Input
- USB Memory
- Ethernet Input
- Composite A/V Input / Output: 2 In
- Analog Audio Inputs / Output: 4 In
- Phono Input
- Digital Inputs / Output: 2 In (Optical 1, Coaxial 1)
- Pre-Amp Outputs: Zone 2
- Headphone Output
- Front A/V Inputs: USB, 3.5mm stereo input
- AM/FM Presets: 40
Installation
- Home Menu: GUI with System/Network Setup Menu
- Zone 2 Sources: Analog, Bluetooth, USB and NET
- 12 Volt Trigger (Assignable): 1 out
- RS-232C
- IR Serial Remote In/Out: 1 In
- Network Firmware Update
- Versatile Speaker Configuration: FRONT, CENTER, SURROUND, SURROUND BACK/HEIGHT/ Bi-AMP, ZONE 2
- FL Dimmer
- Function Rename
- Remote: Pioneer Control App
- Sleep Timer
- Detachable Power Cord
Physical
- Front Panel: Brushed
- Speaker Terminals: 9 Large
- Dimensions: 17.1 x 6.8 x 14.5 in (43.4 x 17.3 x 36.9 cm)
- Weight: 20.7 lbs (9.3 kg)
VSX-LX303
Power
- Amplifier design: Discrete Direct Energy
- Channels: 9.2
- Power output, watts per channel (20 Hz – 20 kHz, THD 0.08 % @ 8 ohms FTC): 100 watts
- Estimated power consumption/standby with HDMI control off: 750 W/0.15 W
- Power output, watts per channel (6 ohms 1 kHz 10 % 1ch Driven): 200 watts
- 4 OHM speaker
Handheld & Internet
- AirPlay
- Made for iPhone and iPod: AirPlay only
- iOS/Android remote control APP: Pioneer Control App
- Internet radio: TuneIn radio
- Pandora
- Streaming audio from PC/network
- Music playback via USB network: MP3, WMA, AAC, Apple Lossless, WAV, FLAC, AIFF, DSD
- Chromecast
- Hi-Res audio: Apple lossless, WAV, FLAC, and AIFF for 192kHz/24bit, DSD for 5.8MHz (via USB or wired network)
- TIDAL music streaming
Decoders & Formats
- Digital Core DSP Engine: Digital Quad-Core 32-bit DSP (Cirrus Logic) + Aureus Floating-Point DSP (TI)
- Audio DACs: 384 kHz/32-bit D/A Conversion with AK4458 (AKM) + PCM5101 (TI)
- High-Definition Copy Protection (HDCP): 2.2
- Dolby Atmos
- Dolby TrueHD
- Dolby Digital Plus
- Dolby Surround
- DTS:X
- DTS Neo:X
- DTS Neural:X
- DTS-HD Master Audio
- HDMI SACD Transfer: Multi: 2.8MHz (PCM Conversion）
Soundfield Calibration
- MCACC
- MCACC Memory: 1
- Phase Control
- Symmetric EQ
- Auto Subwoofer Crossover
Listening Modes
- Auto Surround
- Stream Direct: Direct / Pure Direct
- Advanced Surround: Multiple
- Front Stage Surround Advance
Audio Features
- DSD Music File: 2ch:5.6MHz, Multi:2.8MHz(Multi is only for SACD via HDMI)
- Advanced Sound Retriever
- Tone Control: Multi
- Sound Delay (Lip Sync): 500 ms @ 48k/ 400 ms @ 96k/ 200 ms @ 192k
- Bi-Amp
Video Processing
- 4K 60p Ultra HD Passthrough: HDR10, Dolby Vision Compatible)
- 4K 60p Ultra HD Video Scaler: Ultra HD Upscaling
- 3D Ready
- Audio Return Channel
- HDMI 36-bit Deep Color
- x.v.Color
- Video Converter to HDMI
- Video Scaler: 1080p -> 4k
- Super Resolution
Connectivity
- HDMI Input / Output: 7 in / 2 out
- Wi-Fi Built-In: Dual Band 5 GHz/2.4 GHz
- Bluetooth Built-In: Version: 4.1, Profile: A2DP/AVRCP, Codec: SBC/AAC
- Component Video Input / Output: 1 In (Assignable)
- USB Memory Input
- USB Memory
- Ethernet Input
- Composite A/V Input / Output: 2 In
- Analog Audio Inputs / Output: 4 In
- Phono Input
- Digital Inputs / Output: 2 In (Optical 1, Coaxial 1)
- Pre-Amp Outputs: Zone 2
- Headphone Output
- Front A/V Inputs: USB, 3.5mm stereo input
- AM/FM Presets: 40
Installation
- Home Menu: GUI with System/Network Setup Menu
- Zone 2 Sources: Analog, Bluetooth, USB and NET
- Zone 3 Sources: Analog, Bluetooth, USB and NET
- 12 Volt Trigger (Assignable): 2 out
- RS-232C
- IR Serial Remote In/Out: 1 In
- Network Firmware Update
- Versatile Speaker Configuration: FRONT, CENTER, SURROUND, SURROUND BACK/HEIGHT/ Bi-AMP, ZONE 2
- FL Dimmer
- Function Rename
- Remote: Pioneer Control App
- Sleep Timer
- Detachable Power Cord
Physical
- Front Panel: Brushed
- Speaker Terminals: 9 Large
- Dimensions: 17.1 x 6.8 x 14.5 in (43.4 x 17.3 x 36.9 cm)
- Weight: 23.8 lbs (10.7 kg)
VSX-LX503
Power
- Amplifier design: Discrete Direct Energy
- Channels: 9.2
- Power output, watts per channel (20 Hz – 20 kHz, THD 0.08 % @ 8 ohms FTC): 120 watts
- Estimated power consumption/standby with HDMI control off: 850 W/0.15 W
- Power output, watts per channel (6 ohms 1 kHz 10 % 1ch Driven): 230 watts
- 4 OHM speaker
Handheld & Internet
- AirPlay
- Made for iPhone and iPod: AirPlay only
- iOS/Android remote control APP: Pioneer Control App
- Internet radio: TuneIn radio
- Pandora
- Streaming audio from PC/network
- Music playback via USB network: MP3, WMA, AAC, Apple Lossless, WAV, FLAC, AIFF, DSD
- Chromecast
- Hi-Res audio: Apple lossless, WAV, FLAC, and AIFF for 192kHz/24bit, DSD for 5.8MHz (via USB or wired network)
- TIDAL music streaming
Decoders & Formats
- Digital Core DSP Engine: Digital Quad-Core 32-bit DSP (Cirrus Logic) + Aureus Floating-Point DSP (TI)
- Audio DACs: 384 kHz/32-bit D/A Conversion with AK4458 (AKM) + PCM5101 (TI)
- High-Definition Copy Protection (HDCP): 2.2
- Dolby Atmos
- Dolby TrueHD
- Dolby Digital Plus
- Dolby Surround
- DTS:X
- DTS Neo:X
- DTS Neural:X
- DTS-HD Master Audio
- HDMI SACD Transfer: Multi: 2.8MHz (PCM Conversion）
Soundfield Calibration
- MCACC
- MCACC Memory: 1
- Phase Control
- Symmetric EQ
- Auto Subwoofer Crossover
Listening Modes
- Auto Surround
- Stream Direct: Direct / Pure Direct
- Advanced Surround: Multiple
- Front Stage Surround Advance
Audio Features
- DSD Music File: 2ch:5.6MHz, Multi:2.8MHz(Multi is only for SACD via HDMI)
- Advanced Sound Retriever
- Tone Control: Multi
- Sound Delay (Lip Sync): 500 ms @ 48k/ 400 ms @ 96k/ 200 ms @ 192k
- Bi-Amp
Video Processing
- 4K 60p Ultra HD Passthrough: HDR10, Dolby Vision Compatible
- 4K 60p Ultra HD Video Scaler: Ultra HD Upscaling
- 3D Ready
- Audio Return Channel
- HDMI 36-bit Deep Color
- x.v.Color
- Video Converter to HDMI
- Video Scaler: 1080p -> 4k
- Super Resolution
Connectivity
- HDMI Input / Output: 7 in / 2 out
- Wi-Fi Built-In: Dual Band 5 GHz/2.4 GHz
- Bluetooth Built-In: Version: 4.1, Profile: A2DP/AVRCP, Codec: SBC/AAC
- Component Video Input / Output: 1 In (Assignable)
- USB Memory Input
- USB Memory
- Ethernet Input
- Composite A/V Input / Output: 2 In
- Analog Audio Inputs / Output: 6 In
- Phono Input
- Digital Inputs / Output: 2 In (Optical 1, Coaxial 1)
- Pre-Amp Outputs: Zone 2
- Headphone Output
- Front A/V Inputs: USB, 3.5mm stereo input
- AM/FM Presets: 40
Installation
- Home Menu: GUI with System/Network Setup Menu
- Zone 2 Sources: Analog, Bluetooth, USB and NET
- Zone 3 Sources: Analog, Bluetooth, USB and NET
- 12 Volt Trigger (Assignable): 2 out
- RS-232C
- IR Serial Remote In/Out: 1 In
- Network Firmware Update
- Versatile Speaker Configuration: FRONT, CENTER, SURROUND, SURROUND BACK/HEIGHT/ Bi-AMP, ZONE 2
- FL Dimmer
- Function Rename
- Remote: Pioneer Control App
- Sleep Timer
- Detachable Power Cord
Physical
- Front Panel: Brushed
- Speaker Terminals: 11 Large
- Dimensions: 17.1 x 7.5 x 15.3 in (43.4 x 19 x 38.8 cm)
- Weight: 23.8 lbs (13 kg)
Included
- Pioneer’s 3-year warranty on parts and labor
