SEEED Rainbow Cube Kit RGB 4 x 4 x 4

SEEED Rainbow Cube Kit RGB 4 x 4 x 4

bookmark_border
Where's the price?
To negotiate the best possible price for our customers, we agree to hide prices prior to logging in.
289 requests
Product Description
The SEEED Rainbow Cube Kit allows you to create and manipulate visually stunning designs in the form of a light cube. Made up of 64 8-millimeter RGB LEDs with a built-in 3.3-volt 1-amp LDO, it’s great for experimenting and tinkering Read More

The Cube Is Your Canvas

The SEEED Rainbow Cube Kit allows you to create and manipulate visually stunning designs in the form of a light cube. Made up of 64 8-millimeter RGB LEDs with a built-in 3.3-volt 1-amp LDO, it’s great for experimenting and tinkering. The main Cube in the drop comes pre-assembled (no soldering necessary) with a Rainbowduino—an Arduino-compatible driver that controls the LEDs. This version can be plugged into a PC or Mac with the XBee socket and is controlled with free design software.

SEEED Rainbow Cube Kit RGB 4 x 4 x 4
SEEED Rainbow Cube Kit RGB 4 x 4 x 4
SEEED Rainbow Cube Kit RGB 4 x 4 x 4

Product Video

Specs

  • 64 8-mm RGB diffused LEDs
  • XBee compatible socket
  • 4 x 4 x 4 arrangement
  • Provides a 3.3V/1 Ampere LDO for power the Cube with unregulated DC 6-9V. (Useful when not powered by USB)
  • Provides 8 red, 8 green, and 8 blue common cathode pins along with 8 Vcc pins in a 2 x 16 header pin

Rainbowduino v3.0

  • Constant current output: 20.8 mA
  • Pin headers: 2 x 16 for connecting multiplexed LEDs
  • Maximum LEDs driving capability: 192 (i.e 8 x 8 x 3)
  • Supported LED displays: 4 x 4 x 4 RGB Cube & 8 x 8 RGB LED Matrix
  • USB to UART: FT232RL
  • DC supply: USB powered or External 6V~12V DC
  • Built-in voltage regulator: 5V / 1A

Included

Assembled Version

  • Rainbow Cube Kit ( Assembled, with acrylic box)
  • Rainbowduino v3.0
  • Power adapter
  • USB cable

Shipping

Estimated ship date is Aug 15, 2018 PT.

Payment will be collected at checkout. After this product run ends, orders will be submitted to the vendor up front, making all orders final.
