Optimizing audio resolution and user experience, Shanling’s new M8 digital audio player is a must-have for high-fidelity, pocket-ready playback. To integrate seamlessly with your favorite apps and devices, the touchscreen-equipped M8 features a powerful 8-core Snapdragon 430 processor—plus Shanling’s unique AGLO technology, which correctly processes music from apps to avoid degradation from Android systems. The M8 also comes with dual AK4499EQ DACs and an XMOS XUF208 USB interface to deliver Hi-Res decoding all the way up to 32-bit, 768-kilohertz PCM and native DSD512. In a glowing review on Headfonics, contributor James Tan calls the M8’s sound “elegant, effortless, and expressive with dense and rich details.” Connect and listen wirelessly via Bluetooth 5.0 with support for the latest aptX codecs, and use the interchangeable headphone sockets to fit your setup.
General
- Shanling
- DAC chip: (2) AK4499EQ
- Audio formats supported: DSF / DFF / ISO / DXD / APE / FLAC / WAV / AIFF / AIF / DTS / MP3 / WMA / ACC / OCG / ALAC / MP2 / M4A / AC3 / M3U / M3UB
- MQA decoding
- Maximum sampling rate: 32-bit / 768 kHz PCM and Native DSD512
- Gain settings: Low, High, Turbo
- Digital filters: 6 digital filters
- Storage: 64-gigabytes (built in) and micro SD card slot (up to 2-terabytes supported)
- Operating system: Open Android 7.1 with AGLO (Android Global Lossless Output)
- Connectivity: Wi-Fi (2.4 G / 5G / file transfer), SyncLink, DLNA, AirPlay, OTA updates
- Touchscreen resolution: 1080 x 1920
- Touchscreen size: 5 in (12.7 cm)
- Overall dimensions: 5.4 x 3.2 x 0.8 in (13.8 x 8 x 2 cm)
- Weight: 12.1 oz (342 g)
Bluetooth
- Bluetooth version: Bluetooth 5.0
- Bluetooth codecs supported (transmitting): LDAC, LHDC, aptX HD, aptX, SBC
- Bluetooth codecs supported (transmitting): LDAC, LHDC, aptX HD, aptX LL, aptX, AAC, SBC
Single-Ended Output
- Output power (Low Gain): 18 mW at 32 ohms
- Output power (High Gain): 48 mW at 32 ohms
- Output power (Turbo Gain): 260 mW at 32 ohms
- Frequency response: 20 Hz – 40 kHz (0.5 dB)
- THD + N: 0.00089%
- Channel separation: 75 dB at 32 ohms
- SNR: 121 dB
- Dynamic range: 121 dB
- Noise floor: > 115 dB (1.7 uV)
- Output impedance: < 1 ohm
Balanced Output
- Output power (Low Gain): 71 mW at 32 ohms
- Output power (High Gain): 184 mW at 32 ohms
- Output power (Turbo Gain): 840 mW at 32 ohms
- Frequency response: 20 Hz – 40 kHz (-0.5 dB)
- THD + N: 0.00085%
- Channel separation: 115 dB at 32 ohms
- SNR: 123 dB
- Dynamic range: 123 dB
- Noise floor: > 113 dB (2.1 uV)
- Output impedance: < 2 ohms
Battery
- Charging: DC 5V / 2A, QC3.0 support
- Battery capacity: 7,000 mAh
- Battery life: 14 hours (single-ended output), 9 hours (balanced output)
- Leather case
- Interchangeable headphone sockets
