TCG TRD3
Desktop DAC/Amplifier
You’re ready to spruce up your sound, but you don’t know where to start. Updated from TCG’s widely praised TRD2, the TCG TRD3 DAC/AMP is a desktop DAC/headphone amplifier combo that sports a user friendly design and killer audiophile sound.
Technology
Capable of up to 32-bit, 192 kHz resolution, the TCG TRD3 DAC/AMP has the ability to drive most audiophile and professional headphones with an impedance of up to 300 Ohms. Utilizing a AKM4390 DAC chip and CM6631A USB receiver, the TRD3 comes equipped with a premium patent power module, independent left and right channel filtering, and full MCU control that lend to its exceptionally practical and simply navigated design.
Construction and Design
Built with aluminum alloy housing that’s been finely sand blasted for a sleek finish, the TRD3 boasts an elegant design to complement any audio gear. The included accessories such as a coaxial cable and 1/4" to 1/8" headphone adapter add convenience and versatility to your home entertainment system.
Specs
- TCG
- USB input: 16 bit – 32 bit, 32 kHz – 192 kHz
- Optical fiber, coaxial input: 16 bit – 24 bit, 32 kHz – 192 kHz
- Output levels: 2 Vrms
- THD+N: <0.0018%
- Dynamic range: > 116 dB
- Signal to noise ratio: > 117 dB
- Channel separation: > 110 dB
- Amp output power: 32 @ 210mW, 64 @ 270mW and 150 @ 220mW
- Impedance adaptation: 32 - 300 Ohms
- THD+N: 0.001% @ 10 mW
- Power adapter output DC9V (12W) / input: AC100-240V (CE, FCC, CCC, PSE certification)
- North American Plug
- 3.7 x 5.3 x 1 in (95 x 137 x 27 mm)
- 1.87 lbs (0.85 kg)
Included
- USB cable
- Machine foot
- Coaxial cable
- 1/4 to 1/8 in (6.5 mm to 3.5 mm) adapter
Shipping
Estimated ship date is June 4, 2015 PT.
Payment will be collected at checkout. After this product run ends, orders will be submitted to the vendor up front, making all orders final.
