Topping D90 MQA Version DAC

Topping D90 MQA Version DAC

bookmark_border
Where's the price?
To negotiate the best possible price for our customers, we agree to hide prices prior to logging in.
995 requests
·
5 Sold
Product Description
Expanding its already-renowned line of digital-to-audio converters, Topping is taking a step toward higher-end performance with the D90 MQA DAC. This powerful and feature-loaded DAC is equipped with AKM's flagship DAC chip (the AK4499) and XMOS for support up to 32-bit 768kHz, DSD51 audio, and MQA decoding Read More

High-End Audio Conversion With Bluetooth Connectivity

Expanding its already-renowned line of digital-to-audio converters, Topping is taking a step toward higher-end performance with the D90 MQA DAC. This powerful and feature-loaded DAC is equipped with AKM's flagship DAC chip (the AK4499) and XMOS for support up to 32-bit 768kHz, DSD51 audio, and MQA decoding. It also features a four-channel design in which all outputs are made parallel to one channel to improve performance. These inputs include: AES, USB, optical, Coaxial, IIS, and BT. Lastly, the D90 uses a CSR8675 chipset to support Bluetooth 5.0 and LDAC/AAC/S-BC/APTX/APTX LL/APTX HD protocols. It can achieve an impressive 24-bit 96kHz Hi-Res transmission with LDAC.

Note: All models ship with a US power plug. This run is for the D90 MQA in black.

Topping D90 MQA Version DAC
Topping D90 MQA Version DAC

Color

Specs

  • Topping
  • DAC Chip: AKM AK4499
  • USB Interface: XMOS XU-216
  • SPDIF Interface: AK4118
  • Bluetooth: 5.0 / Apt-X HD / LDAC
  • Inputs: 1 x I2S LVDS (HDMI), 1 x USB-B (XMOS), 1 x Optical Toslink, 1 x Coaxial SPDIF, 1 x AES/EBU
  • Outputs: 1 x Balanced XLR, 1 x Single-ended RCA
  • USB supported sampling rates: PCM up to 32bit 768kHz; Native DSD up to DSD512 / DSD DoP up to DSD256
  • I2S supported sampling rates: PCM up to 32bit 768kHz; DSD up to DSD512
  • Coaxial, Optical, AES supported sampling rates: PCM up to 24bit 192kHz
  • RCA output voltage: 2Vrms at 0dBFS
  • XLR output voltage: 4Vrms at 0dBFS
  • Dynamic range (A-Weighting): 128dB
  • Power supply: AC 110V/220V 50/60Hz (switchable) via IEC (cable included)
  • Case material: Aluminium

Included

  • Remote control
  • USB Cable
  • AC Cable
  • Bluetooth antenna
  • User manual
