XD004 Hot-Swappable 4-Key Aluminum Macropad
01 / 11
XD004 Hot-Swappable 4-Key Aluminum Macropad
bookmark_border
Where's the price?
To negotiate the best possible price for our customers, we agree to hide prices prior to logging in.
496 requests
·
74 Sold
Product Description
Maybe you don’t need a full macro pad, or maybe the appeal of a tiny one is just too much to pass up. This mini four-key macro pad won’t make a big footprint on your desktop, but it can have a huge impact Read More
You Might Also Like
search
close
Sort by: Top Conversations
keyboard_arrow_downduckfarts
71
Jan 25, 2019
If this is based on the same software as the XD002, STAY AWAY from this one.
By "macro pad", they mean you can only select from a list of predefined keys or key combinations, or you can save a text snippet for it to type in; you cannot program your own key combinations.
The preset keys you can set are:
- Any keyboard key
- Standard media control functions
- Power/Sleep/Wake buttons
- Mouse buttons L/R/M/4/5
- Ctrl+A/X/C/V
- Turn LEDs on/off
- Change layer
e_kul
11
Jan 29, 2019
Seriously... What is a "Macro Pad" that can't use macros? This is exactly what I want but with Maco capabilities. Such a shame.
SuperKrog
18
Aug 17, 2019
duckfartsplease tell me how to program it at least for basic keys... TMK website has the button grayed and I can't proceed with the flash.
I followed every instruction available here and there
gorbachev
50
May 23, 2019
You know, that's an awesome point. Thanks for commenting. I will forever be in your debt for your wisdom and guidance.
puddingfarmer
186
May 24, 2019
gorbachevWHOA. Hang on a second here. I'm the one who started you down this road to success. May I have partial credit??
smileybarry
142
Jan 25, 2019
drunkenJNo, probably the same basic firmware as their XD002. You can't set your own key combinations for the macros and they're fairly basic. (no hold, double tap, etc.)
shadyinc
318
May 23, 2019
PSA: No QMK support. That means you can't reprogram the buttons easily. Save your moolah if you were looking for one.
(Edited)
shadyinc
318
May 27, 2019
They’re programmable but not as easily as one can do that using QMK. You should read other comments how people are stuck with a product and no information how to flash/program it.
theMillerDave
188
Apr 24, 2019
So, I received 2 of these from Massdrop yesterday - no keycaps, no instructions, just the case components (al and acrylic), screws, bumpons, and PCB.
After some digging (it comes out of the box as a 4-key keyboard with the keys L O V E preprogrammed - hardly a macro board), here's what I found:
Some good news: it runs TMK (ATMega16u2).... Bad news: I cannot find the full source of the firmware, and the thing must be configured and flashed via a customized instance of TKG (TMK Keymap Generator) webapp at http://https://xd.tkg.io . I can get the Keymap source, but the other source code specific to the hardware has not been made public. Without this code, true macros are not possible, as this specific TKG is quite limited. I'd love to at least be able to get the pin mappings for the matrix, leds, and ws2812 underglow array (so that I could spin up a version of QMK for it). Also worth mentioning, those looking for one of these can search for xiudi xd004 (kprepublic and aliexpress are carrying it at half the cost of what it was selling for here).
Massdrop: can we do anything to get the full TMK firmware source for this board from Xiudi?
doubleotwo
25
May 11, 2019
i payed 30 + 30 for customs for this piece of S*** which is not working at all. I followed the steps that i got from kbrepublic after gotten a link here, how much effort is it to put a manual here... im very sad about this. How can i return it so i can get back my money ? I do not want a replacement cause customs will charge me 30 for it ...
Liberty
345
Feb 18, 2021
That makes an even bigger difference than can be initially seen. The price of $16 is well inside the tax-free limit, so it is, e.g. $60 (30+30) vs. $16 for a European customer. Not to mention that sellers at AE will write whatever price you want on the shipping label.
LevelSteam
Jan 25, 2019
Can I opt out of the box switches that may or may not ruin my keycaps?
LevelSteam
Jan 25, 2019
brneorI mean, it's not a *huge* deal. It's four switches. But why it's being offered as standard and why we have to do the "are they/aren't they" again doesn't make sense to me when a switchless option is possible.
Xanderjones93
1
Jul 4, 2019
so other than the obvious failing on them sending us screws that are far too small, has anyone had any luck programming this POS following manufacturer instructions because mines a bust
Showing 39 of 67
