xDuoo XA-10 DAC/Amp
Hi-Fi Audio With Fully Balanced Outputs
Handling audio conversion and amplification with powerful components and a fully balanced circuit, the XA-10 DAC/amp from xDuoo is a hi-fi foundation fit for any setup. Dual AK4493EQ DAC chips take care of digital-to-audio conversion, enabling the XA-10 to support PCM 32-bit, 768 kilohertz, DSD 512, and full MQA decoding. Double amplifier chips complete the balanced circuit, taking noise interference and crosstalk to near-zero levels. To accommodate different hardware, the XA-10 features 6.35-millimeter single-ended and RCA outputs, as well as 4.4-millimeter and 4-pin XLR balanced outputs with maximum power outputs of 4,000 milliwatts. Connect via USB, optical, coaxial, RCA, or Bluetooth with support for aptX HD, aptX Low Latency, and LDAC codecs.
Note: This product is rated for 110V only. All units ship with US plug.
Specs
- xDuoo
- Power Supply: 110V
- DAC chipset: (2) AK4493EQ chips
- Screen: 0.96 in (2.4 cm) OLED
- Inputs: USB, optical, coaxial, RCA, Bluetooth
- Outputs: 6.35 mm (single-ended), RCA, 4.4 mm (balanced), 4-pin XLR (balanced)
- Bluetooth codecs supported: SBC, AAC, aptX, aptX HD, aptX LL, LDAC
- Sampling rates supported (USB): PCM 16 – 32-bit / 44.1 – 768 kHz, DSD64 – 512, DXD 24 – 32-bit / 352.8 – 384 kHz, MQA 16 – 32-bit / 44.1 – 384 kHz
- Sampling rates supported (optical / coaxial): PCM 16 – 24-bit / 44.1 – 192 kHz, DSD64
- Output power (single-ended): 3,000 mW (32 ohms at 1 kHz)
- Output power (balanced): 4,000 mW (32 ohms at 1 kHz)
- Gain: + 16 dB
- Suitable headphone impedance: 16 – 600 ohms
- SNR (single-ended): 115 dB
- SNR (balanced): 120 dB
- THD: 0.0008%
- Crosstalk (single-ended) 73 dB
- Crosstalk (balanced): 108 dB
- Dimensions: 8.7 x 2.8 x 3.9 in (22 x 7 x 10 cm)
- Weight: 2 lbs (0.9 kg)
Shipping
Estimated ship date is June 7, 2024 PT.
Payment will be collected at checkout. After this product run ends, orders will be submitted to the vendor up front, making all orders final.
