Sparroew
10
Dec 22, 2018
bookmark_border
I finally got some time to work on this and sat down to follow the instructions to finally get my Planck working. I reached step seven, and after unplugging the ISP flasher and plugging the keyboard back into the computer, I am no longer able to do anything. "DFU Device Connected" does not appear, the keyboard does not respond to any input, the lights do not come on and if I try to click flash, I get "There are no devices available." Please let me know where I went wrong. I am really at the end of my patience for this keyboard.
Dec 22, 2018
Lukelex
7
Jan 13, 2019
bookmark_border
Same problem here
Jan 13, 2019
ckofy
64
Jan 26, 2019
bookmark_border
After successful flashing of boot loader, I had the same issue that QMK Toolbox does not recognize the keyboard. I was able to successfully flash firmware using QMK development environment in Linux. QMK Toolbox is unable to detect Planck Light after pressing reset button even now when it is functional. EDIT: Well, I found out why QMK Toolbox was unable to detect the board. This is because drivers for AT90USB128 chips was not installed to the Windows. I downloaded the Amtel Flip tool, and it has drivers in usb folder, which may be pointed to from Device Manager to use for Unknown device as the AT90USB128 is.
(Edited)
Jan 26, 2019
