Seeed LoRa/LoRaWAN Gateway Kit for Raspberry Pi
Build Your Own Wireless Network
Create a low-power, wide-area wireless network with the Seeed LoRa/LoRaWAN Gateway Kit. It includes an RHF0M301 gateway module, an RHF4T002 PRI two-bridge adapter, an 8-gigabyte micro-SD card, a USB-to-UART adapter, a rubber duck antenna, two micro-USB cables, an ethernet cable, and a standard power adapter. The 10-channel gateway module creates a 915-megahertz local server that gives you the ability to collect and transfer data among your LoRa nodes. The gateway can be connected to a Raspberry Pi via the RHF4T002 PRI two-bridge adapter for instant network access. The gateway is also compatible with Seeeduino and Grove devices, so you can develop IoT sensors and build prototypes on your network.
Note: At checkout, you can add a Raspberry Pi 3 B+ (+ $35).
Optional Raspberry Pi 3 B+ (+ $35)
Following the success of the first two versions, the Raspberry Pi 3 B+ makes significant improvements to the speed and performance. This version features a 64-bit quad-core processor that runs at 1.4 GHz, as well as dual-band 2.4 GHz and 5 GHz wireless LAN. Bluetooth 4.2 and BLE let you connect compatible devices. With a host of plugins, connectors, pins, and ports, it’s fully equipped to help you start prototyping and exploring the Internet of Things.
Specs: Raspberry Pi 3 B+ (Optional)
- Model number: 102110138
- Processor: Broadcom BCM2837B0, Cortex-A53 64-bit SoC at 1.4GHz
- Memory: 1GB LPDDR2 SDRAM
- Connectivity: 2.4GHz, 5GHz IEEE 802.11.b/g/n/ac wireless LAN
- Bluetooth: 4.2, BLE
- Gigabit Ethernet over USB 2.0 (maximum throughput 300Mbps)
- Inputs: 4 USB 2.0 ports
- Extended 40-pin GPIO header
- Video sound: HDMI; MIPI DSI display port; MIPI CSI camera port; 4 pole stereo output and composite video port
- Multimedia: H.264, MPEG-4 decode (1080p30); H.264 encode(1080p30); OpenGL ES 1.1, 2.0 graphics
- SD card support: Micro SD format for loading operating system and data storage
- Input power: 5V/2.5A DC via micro USB connector; 5V DC via GPIO header; Power over Ethernet (PoE)–enabled (requires separate PoE HAT)
- Operating temperature: 32–122° F (0–50° C)
- Dimensions: 4.7 x 2.9 x 1.3 in (12 x 7.5 x 3.4 cm)
- Weight: 2.6 oz (75 g)
Included
- RHF0M301 gateway module
- RHF4T002 PRI 2-bridge adapter
- 8GB Class 10 micro-SD card
- USB-to-UART adapter
- 0dBi rubber duck antenna
- Micro-USB cable: 7.8 in (20 cm)
- Micro-USB cable: 39 in (100 cm)
- RJ45 ethernet cable: 78.7 in (200 cm)
- 5V/2.1A American standard adapter with micro-USB connector
Shipping
Estimated ship date is Apr 1, 2019 PT.
Payment will be collected at checkout. After this product run ends, orders will be submitted to the vendor up front, making all orders final.
