Matrix Mini-i Pro 2SK DAC/Amp
Matrix Mini-i Pro 2SK DAC/Amp
bookmark_border
Where's the price?
To negotiate the best possible price for our customers, we agree to hide prices prior to logging in.
Product Description
The Matrix Mini-i Pro 2SK packs the functionality of a DAC, headphone amp, and speaker preamp into one sleek, compact package. The star of the show is the ES9026PRO chip: an audiophile-grade DAC primed to be the center of your audio system Read More
All in One

The Matrix Mini-i Pro 2SK packs the functionality of a DAC, headphone amp, and speaker preamp into one sleek, compact package. The star of the show is the ES9026PRO chip: an audiophile-grade DAC primed to be the center of your audio system. The built-in preamp can be configured for a +18dB digital gain, which eliminates the need for an additional preamp and is great for low-gain active speakers. CNC machined with an anodized surface, this looks and feels like a high-quality piece of gear. This version differs slightly from the standard Mini-i Pro 2S, as it doesn't include Bluetooth or a remote.

Note: At checkout, choose black or silver.

Color Options
Specs

Digital Input

  • AES: PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, DSD DSD64 (DoP)
  • Coaxial: PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, DSD DSD64 (DoP)
  • Optical: PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, DSD DSD64 (DoP)
  • USB: PCM 16-32Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, DSD DSD64/DSD128 (DoP)  DSD64/DSD128/DSD256 (ASIO Native)
  • Frequency band: 2.402GHz - 2.480GHz
  • Power level: Class II
  • Operating distance: 10-15m
  • Latency: <130ms

System Support

  • Windows7/8/8.1/10 systems need to install the supplied drivers
  • Mac OS X10.6.4 and above version without installing drivers
  • Most Android devices can be used via OTG cable
  • iOS devices can be used via the Apple Camera Connection Kit

Analog Output: XLR

  • SNR: > -123dB 20Hz-20kHz A-Weighting
  • THD+N: <0.0003% at 1kHz A-Weighting
  • Frequency response: 20Hz-20kHz (+0.01dB/-0.02dB)
  • Crosstalk: >-130dB @1kHz
  • XLR output: 4Vrms Fixed at 0 dBFS DAC MODE, 0-4Vrms Adjustable at 0 dBFS PRE MODE

Analog Output: RCA

  • SNR: > -120dB 20Hz-20kHz A-Weighting
  • THD+N: <0.0005% at 1kHz A-Weighting
  • Frequency response: 20Hz-20kHz (+0.01dB/-0.02dB)
  • Crosstalk: >-126dB @1kHz
  • RCA output: 2Vrms Fixed at 0 dBFS DAC MODE, 0-2Vrms Adjustable at 0 dBFS PRE MODE

Headphone Output

  • SNR: >-116dB 20Hz-20kHz A-Weighting
  • THD+N: <0.0007% at 1kHz A-Weighting at 300ohms 25mW
  • Frequency response: 20Hz-20kHz (+0dB/-0.1dB)
  • Crosstalk: >-126dB @1kHz
  • Headphone output impedance: 10ohms
  • Headphone output power: 820mW at 33ohms at THD+N = 0.1%,
  • 210mW at 300ohms at THD+N = 0.1%, 110mW at 600ohms at THD+N = 0.1%

Power

  • Power voltage: 230V position is fit for AC220V-240V 50/60Hz,
  • 115V position is fit for AC100V-120V 50/60Hz
  • Power consumption: <10W

Physical

  • Dimensions: 6.6 x 8.1 x 1.9 in (168 x 205 x 47 mm), including protrusions
  • Weight: 2.9 lbs (1.3 kg)
Included
  • Quick-start guide
  • Power cord
  • USB cable
Shipping

All orders will be shipped by Drop.

Estimated ship date is Oct 29, 2018 PT.

After this product run ends, payment will be collected and orders will be submitted to the vendor up front, making all orders final. Check the discussion for updates on your order.
