ID75 Hot-Swappable Ortholinear Keyboard Kit
ID75 Hot-Swappable Ortholinear Keyboard Kit
bookmark_border
Where's the price?
To negotiate the best possible price for our customers, we agree to hide prices prior to logging in.
189 Sold
Product Description
Ortholinear keyboards are designed to increase efficiency and reduce finger travel when typing. Though it’s large for an ortholinear board, the ID75 gives you free reign over every key—so, if you get good with it, it’s bound to make work and play a lot more fun and effective ... Read More

search
Surging
1
Jul 19, 2019
bookmark_border
Dear friends, has been out of stock, has not bought the friend, may come to my shop, welcome everybody's patronize. https://www.aliexpress.com/store/5072109?spm=5261.11152143.header.29.147f3e5f5s8CCf
search

Jul 19, 2019
jamesk1
1
Jul 19, 2019
bookmark_border
I finally worked out how to flash a hex file downloaded from https://config.qmk.fm/#/idobo/LAYOUT_ortho_5x15 directly to the board, without going through the process of "sudo make idobo:layoutname:dfu" (linux). 1) https://docs.qmk.fm/#/faq_build?id=linux-udev-rules You don't need to use sudo to flash if you follow this guide (you only need this line): # Atmel ATMega32U4 SUBSYSTEMS=="usb", ATTRS{idVendor}=="03eb", ATTRS{idProduct}=="2ff4", MODE:="0666" 2) If you've cloned the QMK git repo you'll find you have a new program, dfu-programmer. https://docs.qmk.fm/#/faq_build?id=can39t-program-on-linux I have a script I use to program a downloaded hex file in one step. During the initial "sleep 5" you put the board into reset mode: xterm -e "sleep 5;dfu-programmer atmega32u4 erase;dfu-programmer atmega32u4 flash /path/to/hex/file/idobo_layoutname.hex ;dfu-programmer atmega32u4 reset"
(Edited)
Jul 19, 2019
KeplerS
0
Jul 10, 2019
bookmark_border
How much is shipping to the UK?
Jul 10, 2019
Geo.Li
4
Jul 10, 2019
bookmark_border
Keycaps????
Jul 10, 2019
Whisper
4
Jul 13, 2019
bookmark_border
This doesn't come with keycaps.
Jul 13, 2019
MooshMooshMoosh
46
Jul 8, 2019
bookmark_border
Question: How would you place a space bar? Or is this completely macro orientated?
Jul 8, 2019
nomaded
97
Jul 9, 2019
bookmark_border
If I wanted a space bar that was larger than 1u, I would probably choose a 3u (though I'm not sure how easy it would be get such a cap) right in the middle of the bottom row. You would probably want to put a single switch in the middle and leave the two sides unpopulated (not sure if that does anything weird with the circuitry though). Then customize your layout via QMK (either directly via the source code or via one of the various web-based configurators). That said, I've been using a 1u for space for over 6 years now, since getting my first ErgoDox. But that works for me and my hands, and it might not work for you and your hands. Luckily, this keyboard has hot-swap switches and QMK, so you can customize the layout and feel very easily.
Jul 9, 2019
internetparty
116
Jul 10, 2019
bookmark_border
I don't know what this PCB's layout is, but the other ones I've seen have several configurations including a split spacebar, 2x2u, and 4u options.
Jul 10, 2019
equalunique
361
Jul 8, 2019
bookmark_border
Weird. I feel like this would have been a lot more compelling if the case had threads on the bottom for angled case feet.
Jul 8, 2019
SPOSpartan104
25
Jul 8, 2019
bookmark_border
Available in US without the insert for $5 less but likely still 1 - 2months before arrival. https://smile.amazon.com/dp/B07K3WPXC4/ref=cm_sw_r_cp_apa_i_AM2iDb516DJKV I'm going to go with the drop.com one instead I think but wanted to share
Jul 8, 2019
Kris2014
13
Jul 9, 2019
bookmark_border
I recon that part. But I think when you mount the plate into the case, it should be held flat. I got a prime o and also came with a curved plate. After inserting switches, I just screw it inside out on the case and solder. When it cooled down I remove and install in the correct orientation.
(Edited)
Jul 9, 2019
nomaded
97
Jul 9, 2019
bookmark_border
Because of the 7 screws holding the PCB to the mounting plate, I find the keyboard to be very solid feeling. Most of my other keyboards I've built are all layered acrylic, so this is a nice change in feel. I also prefer the flat bottom case -- I dislike having the back of the keyboard elevated compared to the front. I want flat or having the front elevated compared to the back. But with a nice smooth bottom, it's very easy to add different kinds of rubber feet to adjust tilt/elevation to any preference.
Jul 9, 2019
deaconblue42
81
Jul 8, 2019
bookmark_border
@YanboWu, the Mechkeys.ca QMK guide you link is outdated and has nothing to do with your keyboard. Maybe https://config.qmk.fm/#/idobo/LAYOUT_ortho_5x15 or a link to a page Drop has written might be more appropriate. Better yet, talk to the QMK maintainers about Drop maintaining the port they did of your keyboard? https://github.com/qmk/qmk_firmware/tree/master/keyboards/idobo Edit: Nice, they linked the QMK configurator at least. That should help some people.
(Edited)
Jul 8, 2019
alysdexia
33
Jul 8, 2019
bookmark_border
asýmmetric as hell
Jul 8, 2019
nomaded
97
Jul 3, 2019
bookmark_border
search
Finished porting my Atreus62 Dvorak layout over to the ID75. Still working on what I should put in the middle 3 columns. The aluminum case is much heavier than I expected. It also changes the feel of the key switches, or maybe that's just a sound difference. I have Halo Clear switches for letters and numbers. Gateron Black switches for the outside columns and 3 middle columns. And a few Zealios 78g Tactile switches for my thumbs on the bottom row. The keycaps are Carbon SA.
(Edited)
Jul 3, 2019
nomaded
97
Jul 9, 2019
bookmark_border
I'm not sure what you mean here. The labels on the keycaps are not necessarily indicative of what the key itself does. I touchtype, so I never really look at the keyboard. I may keep the middle column empty and add some modifiers to the next set of columns. The middle 3 columns are "extra" for me -- this keyboard appealed to me because the 3 middle columns provide some separation for my hands. That's why I prefer this layout over a Preonic -- the Preonic, for me, is too cramped.
Jul 9, 2019
alysdexia
33
Jul 11, 2019
bookmark_border
Your wrong diction. Columns are vertical; these runs are longitudinal. There are no keys on the bottom.
Jul 11, 2019
