Gustard U16 USB Digital Interface

Gustard U16 USB Digital Interface

bookmark_border
Where's the price?
To negotiate the best possible price for our customers, we agree to hide prices prior to logging in.
154 requests
·
5 Sold
Product Description
Looking to take your DAC to the next level? Boasting a high-end USB interface, the Gustard U16 is a convenient alternative to multi-device systems Read More

Up Your Audio Game

Looking to take your DAC to the next level? Boasting a high-end USB interface, the Gustard U16 is a convenient alternative to multi-device systems. Packed with independent linear power, the USB digital interface features both a 32Bit/768kHz and DSD512 chip. The U16 also comes with coaxial RCA, optical fiber, XLR AES3, and HDMI ports for easier pairing with your existing equipment.

Gustard U16 USB Digital Interface
Gustard U16 USB Digital Interface
Gustard U16 USB Digital Interface
Gustard U16 USB Digital Interface

Specs

  • Gustard
  • USB port: USB Type-B female port, support USB2.0
  • 10M BNC input impedance: 50 Ohm
  • 10M BNC maximum input amplitude: 16dBm
  • RCA coaxial S/PDIF output impedance: 75 Ohm
  • RCA coaxial S/PDIF output level: 500mVpp a 75 Ohm
  • RCA coaxial S/PDIF load: 24bit 44.1k-384k/DOP64-128
  • XLR AES3 output impedance: 110 Ohm
  • XLR AES3 output level: 2.1Vpp at 110 Ohm
  • XLR AES3 load: 24bit 44.1k-384k/DOP64-128
  • OPTICAL TOSLINK port: 24bit 44.1k-192k /DOP64
  • Multi-function BNC output impedance: 75 Ohm
  • S/PDIF output level: 750mVpp at 75 Ohm
  • Word Clock output level: 3.3Vpp MAX at noload
  • S/PDIF support specification (when S/P OUT is selected): 24bit 44.1k-384k/DOP64-128
  • Word Clock output frequency (when WCK OUT is selected): PCM: 44.1k-768k.
  • DSD: 2.82M-22.57M
  • IIS over HDMI interface (non-standard HDMI interface); Differential I2S signal with LVDS output level
  • PCM: 32bit 44.1k-768k, DSD 2.82M-22.57M (DSD64-DSD512)
  • AC power supply: AC 115V/230V 50/60Hz
  • Power consumption: <15W
  • Dimensions: 6.6 x 8.6 x 1.9 in (17 x 22 x 5 cm)
  • Weight: 5.5 lbs (2.5 kg)

Included

  • Power cord

Shipping

Estimated ship date is July 9, 2019 PT.

Payment will be collected at checkout. After this product run ends, orders will be submitted to the vendor up front, making all orders final.
