Xuelin H7 DAC/Amp

Xuelin H7 DAC/Amp

bookmark_border
Where's the price?
To negotiate the best possible price for our customers, we agree to hide prices prior to logging in.
10 requests
2 Sold
Product Description
A do-it-all DAC/amp for the mobile listener, the H7 from Xuelin fits an extensive range of high-performing hardware into a sleek form factor. Handling digital-to-analog conversion, two ES9038Q2M chips achieve a wide dynamic range alongside an ultra-low 112-decibel signal-to-noise ratio and 120-decibel THD + N level Read More

Compact Conversion, Clocking & Amplification

A do-it-all DAC/amp for the mobile listener, the H7 from Xuelin fits an extensive range of high-performing hardware into a sleek form factor. Handling digital-to-analog conversion, two ES9038Q2M chips achieve a wide dynamic range alongside an ultra-low 112-decibel signal-to-noise ratio and 120-decibel THD + N level. The USB interface is an SA9227 asynchronous clock, which delivers precise timing while all but eliminating jitter. On the analog side, OPA2134 and AD8397 amps combine to deliver high-fidelity amplification with enough power to drive any pair of headphones. Switch between 3.5-millimeter single-ended and 2.5-millimeter balanced outputs to fit your needs—and listen for hours on the go, thanks to a 2,900-milliamp lithium battery.

Note: At checkout, choose an H7 with a USB-C (base price) or Lightning (+ $14) input.

Xuelin H7 DAC/Amp
Xuelin H7 DAC/Amp
Xuelin H7 DAC/Amp

Specs

  • Xuelin
  • DAC chipset: (2) ES9038Q2M chips
  • USB clock: SA9227 asynchronous clock
  • Amps: OPA2134, AD8397
  • Housing material: Aluminum
  • Input: USB-C or Lightning
  • Outputs: 3.5 mm (single-ended), 2.5 mm (balanced)
  • SNR: 112 dB (1 kHz)
  • THD + N: 120 dB (1 kHz)
  • Frequency response: 20 Hz – 20kHz
  • Battery: 2,900 mAh, 3.7V
  • Charging: 5V 2A USB charger
  • Dimensions: 3.15 x 3.15 x 0.6 in (8 x 8 x 1.5 cm)
  • Weight: 4.8 oz (135 g)

Shipping

All orders will be shipped by Drop.

Estimated ship date is May 26, 2021 PT.

Payment will be collected at checkout. After this product run ends, orders will be submitted to the vendor up front, making all orders final.
