Whether you are a lifetime musical tinkerer or just curious about synthesizer DIY, the Moog Werkstatt Synth Kit offers a doorway into a world of limitless experimentation and sonic creation. Based on classic Moog circuits, the Werkstatt is a patchable one oscillator analog synthesizer that can be easily assembled with minimal tools and know-how.
Note: At checkout, you can purchase extra patch cables (+$10) as well as the Werkstatt CV Expander (+$39.99). To assemble the Werkstatt you will need a Philips screw driver and a pair of small pliers, no soldering is required at all.
The Moog Wekstatt Kit was originally designed as a teaching tool for exclusive workshops but is now being offered in a no-soldering-required version for public consumption. This compact synthesizer can be used as a tool for discovery or learning but can also be modded and expanded to produce a lifetime of uninhibited auditory invention.
The Moog Werkstatt Synth Kit is both an educational tool and a formidable Moog analog synthesizer. The kit includes a one-octave low note priority keyboard with glide control and an analog output located the rear panel for connecting to external amplifier. A single pin patch bay located on the right side of the console further expands the Werkstatt’s capabilities. Offering a wide variety of signal augmentation including low frequency and voltage oscillators, filters and envelopes, this workstation is a virtual playground of possibilities for those with a curious mind.
• Single VCO with frequency control (8Hz to 16KHz)
• Saw and square waveshapes with control for square pulse width
• Envelope or LFO selectable Mod Source that can be assigned to PWM or Pitch with Amount control
• Ability to PWM the square wave
• Classic 4-Pole Moog Ladder Filter with Resonance control (20Hz-20KHz)
• Select between the Envelope generator and LFO as Mod Source.
• Polarity switch (+/-) and amount knob for control of filter cutoff modulation
• Selectable Square or Triangle waveshape with rate control (2Hz-600Hz)
• Select between the Envelope Generator or ON (Drone)
• Controls for Attack & Decay time with Sustain On/Off switch
• One octave low-note priority legato keyboard with glide control
• VCA Input0V to +5V in VCA EG Mode, +/-2.5V in VCA ON Mode
• VCF Input-5V to +5
• VCO LINEAR FM Input +/-2.5V - NOTE: this is an inverting control input
• VCO EXPONENTIAL FM Input -5V to +5V, 1V/Octave trimmable
• LFO CV Input 5V to +5V – NOTE: Negative CV slows LFO more than the panel
• VCF AUDIO InputUnbuffered/Unmixed AC coupled input to VCF
• Two KB CV Output3V/semitone from 1 keyboard - NOTE: Attenuate for 1V/Octave
• Two TRIG Output 5 msec pulse, 0 to +5 V signal generated from low-note priority
• Two GATE Output0 to +5V signal generated from low-note priority
• Two EG Output0 to +5V signal, Simple ASD or AD type Envelope Generator
• Two LFO Output -2.5 to +2.5V Triangle or Square wave, selected via LFO Switch
• Two VCF Output-2V to +2 V signal for audio or CV uses
• Two VCO Output0V to +5V VCO signal, wave selected by VCO Wave Switch
• Audio Output Nominal +/-1.5V Signal
• Power+12VDC Center Positive with 1.2A Wall transformer
• Power Consumption: 1.8 Watt AVG
