Soundaware P1 Amplifier

Soundaware P1 Amplifier

bookmark_border
Where's the price?
To negotiate the best possible price for our customers, we agree to hide prices prior to logging in.
6 requests
Product Description
No matter what you’re listening to—or how you’re listening to it—the P1 amplifier from Soundaware has the components and build quality to supercharge your sound. Outfitted with balanced pre-amp and headphone amp circuits, each with its own power supply, the P1 can switch seamlessly from driving headphones to power amps to both powered and passive speakers Read More

Headphone Amp, Preamp, Audiophile Staple

No matter what you’re listening to—or how you’re listening to it—the P1 amplifier from Soundaware has the components and build quality to supercharge your sound. Outfitted with balanced pre-amp and headphone amp circuits, each with its own power supply, the P1 can switch seamlessly from driving headphones to power amps to both powered and passive speakers. In all roles, components like a high-performance filter circuit, imported Talema transformers, and four LT ULTRA low-noise, high-current secondary regulators deliver class-leading noise filtering with exceptional sonic details. Tested on an extensive range of headphones, the P1 is tuned to closely resemble the legendary Accuphase C290V in both headphone and preamp modes for maximum musicality.

Soundaware P1 Amplifier
Soundaware P1 Amplifier
Soundaware P1 Amplifier
Soundaware P1 Amplifier
Soundaware P1 Amplifier

Color

Specs

General

  • Soundaware
  • Inputs: Stereo XLR, stereo RCA, SAW_Link
  • Outputs: 6.35 mm headphone (single-ended), four-core XLR headphone, stereo RCA, stereo XLR
  • USB linear power supply interface
  • AC power input
  • Maximum power output: 50 V
  • Voltage: 115 V, 230 V
  • Built-in protections: DC input filtered out, high-temperature cut-out, output short circuit protection
  • Dimensions: 8.7 x 7.9 x 2.2 in (22 x 20 x 5.5 cm)
  • Weight: 8.8 lbs (4 kg)

Preamp Mode

  • THD+N: 0.001%
  • SNR: 126 dB
  • Dynamic Ratio: 121 dB

Headphone Mode

  • THD+N: 0.0007%
  • SNR: 128 dB
  • Dynamic Ratio: 121 dB

Rated Output Power

  • Balanced, 0.003% distortion: 6,000 mW x 2 (30 ohms), 5,690 mW (45 ohms), 4,840 mW (100 ohms), 1,620 mW x 2 (300 ohms), 814 mW x 2 (600 ohms)
  • Balanced, 1% distortion: 6,348 mW x 2 (30 ohms), 6,650 mW (45 ohms), 6,250 mW (100 ohms), 3,479 mW x 2 (300 ohms), 1,740 mW x 2 (600 ohms)
  • Single-ended, 0.003% distortion: 3,152 mW x 2 (30 ohms), 2,689 mW (45 ohms), 1,400 mW (100 ohms), 468 mW x 2 (300 ohms), 236 mW x 2 (600 ohms)
  • Single-ended, 1% distortion: 4,332 mW x 2 (30 ohms), 3,930 mW (45 ohms), 2,590 mW (100 ohm

Included

  • US power cord
  • Owner’s manual
