Topping A50 Headphone Amp
Effortless Amplification With 3 Outputs
The perfect partner for any pair of high-impedance headphones, DAC, or both, the Topping A50 headphone amp delivers powerful amplification to fit any setup. This portable headphone amplifier includes three different headphone outputs—a 6.35-millimeter single end, a 3.5-millimeter single end, and a 2.5-millimeter balanced end—for all types of headphones. It can output an impressive 2200 mW at 64 ohms out of the balanced 2.5-millimeter jack, or 1110 mW at 32 ohms out of the 3.5- and 6.35-millimeter outputs. Sturdy and space-efficient, the A50 pairs well with any DAC—particularly the Topping D50 or D50s.
Note: At checkout, choose a US or an EU plug. Both options are available in black and silver.
Model
Black
Silver
Specs
Topping 3.5 mm / 6.35 mm Headphone Jack
- THD + N: <0.0006% at 1 kHz output = 100 mW (32 ohms); <0.0015% at 20 Hz – 20 kHz output = 100 mW (32 ohms); <0.0006% at 1 kHz output = 12 mW (300 ohms); <0.0006% at 20 Hz – 20 kHz output = 12 mW (300 ohms)
- SNR: 123 dB at 1 kHz
- Dynamic range: 123 dB at 1 kHz
- Frequency characteristics: 20 Hz – 20 kHz (± 0.6 dB); 20 Hz – 40 kHz (± 0.6 dB)
- Output level: 10.6 Vpp at G = L; 20 Vpp at G = H
- Noise: <3 uVrms at G = L; <5 uVrms @ G = H
- Output impedance: <4.7 ohms
- Output: 1110 mW x 2 at 32 ohms THD + N <1%; 160 mW x 2 at 300 ohms THD + N <1%
- Impedance matching: 16–300 ohms
Topping 2.5 mm Balanced Headphone Jack
- THD + N: <0.0016% at 1 kHz output = 100 mW (32 ohms); <0.0022% at 20–20kHz output = 100 mW (32 ohms); <0.0004% at 1 kHz output = 50mW (300 ohms); <0.0004% at 20–20kHz output = 50mW (300 ohms)
- SNR: 123 dB at 1 kHz
- Dynamic range: 123 dB at 1 kHz
- Frequency characteristics: 20 Hz – 20 kHz (± 0.6 dB); 20 Hz – 40 kHz (± 0.6 dB)
- Output level: 21.4 Vpp at G = L; 40 Vpp at G = H
- Noise: <5.0 uVrms at G = L; <10.0 uVrms at G = H
- Output impedance: <9.4 ohms
- Output: 2200 mW x 2 at 64 ohms THD + N <1%; 640 mW x 2 at 300 ohms THD + N <1%
- Impedance matching: 16–600 ohms
Included
- Power adapter
- User manual
